Encrypt Linux hard drive and install Ubuntu Gnome 16.10

This post will explain the steps needed to encrypt a Linux hard drive and install Ubuntu Gnome 16.10. This is Part 3 of the original post Installing Linux Ubuntu Gnome on a Used Windows Laptop with Encryption


  • Arch wiki has best guide for using LVM on LUKS which is what I used
    • I normally used GParted, howerver it was giving me errors. I used gdisk terminal application instead. sgdisk is a more graphical version of gdisk.
  • Create a GPT Partition Table on a new hard drive using gdisk.
    • On my new SSD drive, the drive was unformatted and did not have a partition type. I used gdisk to create a GPT partition table.
  • Write random data to the disk before encrypting the disk. This step takes a while, about 27 minutes on my 276GB disk.
    • I have instructions at Encrypt Hard Drive for Secure Storage in Linux Ubuntu 14.04
      • command to write random data on the drive
        • openssl enc -aes-256-ctr -pass pass:”$(dd if=/dev/urandom bs=128 count=1 2>/dev/null | base64)” -nosalt < /dev/zero | pv -pterb > /dev/sda

      • you will get an error message at the end stating “pv: write failed: No space left on device” and “error writing output file”
        • This is ok and do not worry about the error
  • My mount Points
    • /boot, 512 MB, not encrypted
    • Linux Partion for  the remainder of the disk
      • This will be encrypted with LUKS and then have LVM on top of Luks with have all the other file sytems (/, /swap, and /home)
  • Create a 512 MB unencrypted UEFI /boot partition (/dev/sda1)
    • I have an UEFI Bios
    • Open cgdisk and create partition
      • first sector=2048, size = 512 MB; Type=efi system; Partition Name=uefi-boot
    • This partition was called /dev/sda1 when running the terminal command “sudo blkid
  • Create Linux partition for remainder of the disk. Do not add a file system yet. This will be called /dev/sda2
  • Encrypt remainder of the disk (/dev/sda2 on my system)
    • Verify the disk name to encrypt because it will erase any data
      • You can also use the program “disks” to find the disk name (/dev/sda) or from the terminal use the program “parted”
    • sudo cryptsetup –cipher aes-xts-plain64 –key-size 512 –hash sha512 –iter-time 5000 luksFormat /dev/sda
      • you have to acknowledge that this will erase data: type “YES”
      • Enter a strong passphrase and write it down somewhere
  • Open Encrypted Partition
    • Most of these steps are from an earlier post on encrypting a hard drive
    • Verify the partition /dev/sda2 is a LUKS partition
      • sudo cryptsetup -v isLuks /dev/sda2
      • Output should be “Command successful”
    • Open the encrypted device (decrypt/unlock the device)
      • Then first time the encrypted device is opened, a symbolic link called a “mapping” is created which becomes the name of the LUKS device.
        • For example I chose a descriptive name “luks.linux-os” and the LUKS device will be created at /dev/mapper/luks.linux-os “luks.linux-os” will only be created when the LUKS device is opened.
      • sudo cryptsetup -v luksOpen /dev/sda2 luks.linux-os
  • Create LVM container on the unencrypted LUKS partition
    • see arch wiki LVM
    • You must create a LVM partition if the whole disk is not LVM
    • cgdisk
      • Select “new” to make new LVM partition that takes up the remainder of the disk. Partition name = ubuntu-gnome, and partition type = Linux LVM (code=8e00)
    • Create your physical volumes (PVs). If you have one disk it is best to just create one PV in one large partition. If you have multiple disks you can create partitions on each of them and create a PV on each partition.
      • List available devices
        • lvmdiskscan
          • mine is /dev/sda2
      • create physical volume to /dev/mapper/luks-map-linux
        • pvcreate /dev/mapper/luks-map-linux
        • output “Physical volume “/dev/mapper/luks-map-linux” successfully created.”
      • View the new PV
        • pvdisplay
    • Create your volume group (VG) and add all PVs to it.
      • vgcreate VolGroup00 /dev/mapper/luks-map-linux
        • I had one disk to add, but you can add other disks and partitions to increase the size
    • Create logical volumes (LVs) inside that VG.
      • example
        • lvcreate -L <size> <volume_group> -n <logical_volume>
      • lvcreate -L 30G VolGroup00 -n logvol-root
        • /root partition
      • lvcreate -L 10G VolGroup00 -n logvol-swap
        • /swap partition
      • lvcreate -l 100%FREE VolGroup00 -n logvol-home
        • /home partition
    • View logical volume groups LVG
      • lvdisplay
